Product Introduction
Mechanical Specifications
| Display Type: | TFT display |
| Display Mode: | Passive Matrix |
| Model Number: |
HG-066-6448KSWEG03 |
| Diagonal Screen size: | 1.3 inch |
| Interface: |
4-wire SPI |
| Drive Duty: |
1/48 Duty |
| Number of Pixels: |
240*240 |
| Module Size: |
27.78*39.2(mm) |
| Driver IC: |
ST7789 |
| Active Area: |
23.4*23.4(mm) |
| Pixel Pitch: |
0.19*0.19 (mm) |
| Pixel Size: |
0.21*0.21(mm) |
|
Weight: |
2.6 (g) |
|
Operating Temperature: |
-20~+70℃ |
